有限状态自动机

Posted on | In | | 阅读数

有限状态自动机

leetcode题目 表示数值的字符串

根据上面的描述，现在可以定义自动机的「状态集合」了。那么怎么挖掘出所有可能的状态呢？一个常用的技巧是，用「当前处理到字符串的哪个部分」当作状态的表述。

fig1

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
#include <queue>
#include <map>
#include <iostream>
#include <vector>
#include <set>
#include <stack>
#include <string>
#include <unordered_set>
#include <unordered_map>
#include <algorithm>
#include <cmath>
using namespace std;
class Solution {
public:
    enum State {
        STATE_INITIAL,
        STATE_INT_SIGN,
        STATE_INTEGER,
        STATE_POINT,
        STATE_POINT_WITHOUT_INT,
        STATE_FRACTION,
        STATE_EXP,
        STATE_EXP_SIGN,
        STATE_EXP_NUMBER,
        STATE_END
    };

    enum CharType {
        CHAR_NUMBER,
        CHAR_EXP,
        CHAR_POINT,
        CHAR_SIGN,
        CHAR_SPACE,
        CHAR_ILLEGAL
    };

    CharType toCharType(char ch) {
        if (ch >= '0' && ch <= '9') {
            return CHAR_NUMBER;
        } else if (ch == 'e' || ch == 'E') {
            return CHAR_EXP;
        } else if (ch == '.') {
            return CHAR_POINT;
        } else if (ch == '+' || ch == '-') {
            return CHAR_SIGN;
        } else if (ch == ' ') {
            return CHAR_SPACE;
        } else {
            return CHAR_ILLEGAL;
        }
    }

    bool isNumber(string s) {
        unordered_map<State, unordered_map<CharType, State>> transfer{
            //value的 哈希表表示转移
            {
                STATE_INITIAL, {
                    {CHAR_SPACE, STATE_INITIAL},
                    {CHAR_NUMBER, STATE_INTEGER},
                    {CHAR_POINT, STATE_POINT_WITHOUT_INT},
                    {CHAR_SIGN, STATE_INT_SIGN}
                }
            }, {
                STATE_INT_SIGN, {
                    {CHAR_NUMBER, STATE_INTEGER},
                    {CHAR_POINT, STATE_POINT_WITHOUT_INT}
                }
            }, {
                STATE_INTEGER, {
                    {CHAR_NUMBER, STATE_INTEGER},
                    {CHAR_EXP, STATE_EXP},
                    {CHAR_POINT, STATE_POINT},
                    {CHAR_SPACE, STATE_END}
                }
            }, {
                STATE_POINT, {
                    {CHAR_NUMBER, STATE_FRACTION},
                    {CHAR_EXP, STATE_EXP},
                    {CHAR_SPACE, STATE_END}
                }
            }, {
                STATE_POINT_WITHOUT_INT, {
                    {CHAR_NUMBER, STATE_FRACTION}
                }
            }, {
                STATE_FRACTION,
                {
                    {CHAR_NUMBER, STATE_FRACTION},
                    {CHAR_EXP, STATE_EXP},
                    {CHAR_SPACE, STATE_END}
                }
            }, {
                STATE_EXP,
                {
                    {CHAR_NUMBER, STATE_EXP_NUMBER},
                    {CHAR_SIGN, STATE_EXP_SIGN}
                }
            }, {
                STATE_EXP_SIGN, {
                    {CHAR_NUMBER, STATE_EXP_NUMBER}
                }
            }, {
                STATE_EXP_NUMBER, {
                    {CHAR_NUMBER, STATE_EXP_NUMBER},
                    {CHAR_SPACE, STATE_END}
                }
            }, {
                STATE_END, {
                    {CHAR_SPACE, STATE_END}
                }
            }
        };

        int len = s.length();
        State st = STATE_INITIAL;

        for (int i = 0; i < len; i++) {
            CharType typ = toCharType(s[i]);
            if (transfer[st].find(typ) == transfer[st].end()) {
                return false;
            } else {
                st = transfer[st][typ];
            }
        }
        return st == STATE_INTEGER || st == STATE_POINT || st == STATE_FRACTION || st == STATE_EXP_NUMBER || st == STATE_END;
    }
};

// 作者：力扣官方题解
// 链接：https://leetcode.cn/problems/biao-shi-shu-zhi-de-zi-fu-chuan-lcof/solutions/372095/biao-shi-shu-zhi-de-zi-fu-chuan-by-leetcode-soluti/
// 来源：力扣（LeetCode）
// 著作权归作者所有。商业转载请联系作者获得授权，非商业转载请注明出处。
int main(){
    cout << Solution().isNumber("-.") << endl;
    // string line;
    // while(1){
    // getline(cin, line);
    // cout << Solution().isNumber(line) << endl;
    // }
}
